Name: STS DIN Rail Mounted Single Phase Prepaid Electricity Meter with Class 1.0 Accuracy IP54 Waterproof and 5(60)A Current
Brand: Hunan Stron Smart Co., Ltd
SKU: Ste18
Price: 23.00 USD
Availability: InStock

Casa. > prodotti > Metro pagato anticipatamente astuto di elettricità >

STS DIN Rail Mounted Single Phase Prepaid Electricity Meter with Class 1.0 Accuracy IP54 Waterproof and 5(60)A Current

Class 1.0 Accuracy STS Prepaid Electricity Meter

IP54 Waterproof Single Phase Electricity Meter

5(60)A Current DIN Rail Mounted Meter

Luogo di origine:

Hunan, Cina

Marca:

Stron

Certificazione:

STS Certificate

Numero di modello:

Ste18

Contattaci

Chiedi un preventivo

STS DIN Rail Mounted Single Phase Prepaid Electricity Meter with Class 1.0 Accuracy IP54 Waterproof and 5(60)A Current

Dettagli del prodotto

Tensione nominale:

220V/230V

Intervallo di tensione di lavoro:

30%~120%ONU

Frequenza nominale:

50-60Hz

Attuale:

5(60) A

Classe di precisione:

Classe 1.0 (energia attiva)

Grado di protezione IP:

IP54

Intervallo di temperatura operativo:

-25℃-70℃

Evidenziare:

Class 1.0 Accuracy STS Prepaid Electricity Meter

IP54 Waterproof Single Phase Electricity Meter

5(60)A Current DIN Rail Mounted Meter

Termini di pagamento e spedizione

Quantità di ordine minimo

Prezzo

USD25-USD22 per pc

Imballaggi particolari

Cartoni

Tempi di consegna

151-20 giorni

Termini di pagamento

L/C,T/T,Western Union,Paypal,Alipay

Capacità di alimentazione

10,0000 pcs al mese

Prodotti correlati

STS DIN Rail Mounted Single Phase Prepaid Electricity Meter with Class 1.0 Accuracy IP54 Waterproof and 5(60)A Current

Ottieni il miglior prezzo

Prepaid Token Type Electric Meter Testing Equipment Equipped with Stronpay Vending Software Ensuring High Accuracy and Testing Outcomes

Ottieni il miglior prezzo

IP54 Smart Prepaid Electricity Meter Featuring Unlimited Capacity Nominal Voltage 230V 30 to 120 Percent Ideal for Energy Management Solutions

Ottieni il miglior prezzo

Contatore elettrico GPRS prepagato STS progettato per una facile installazione e manutenzione, garantendo al contempo una misurazione precisa dell'energia

Ottieni il miglior prezzo

Contattaci

Contattaci ora

Descrizione del prodotto

STS DIN Rail Mounted Single Phase RF Electricity Meter for Sub-metering

Product Overview

The Rail-Type Single-Phase Prepaid Meter is a compact, secure, and highly reliable STS-compliant metering solution designed for modern prepaid energy management. With a DIN-rail mounting structure, encrypted token technology, and robust anti-tamper protection, this meter is ideal for apartments, small commercial units, prepaid projects, and smart utility deployments across Africa, Asia, and developing regions.

Key Features

STS Prepaid System

Supports IEC 62053-21/23, IEC62055-31 encrypted token technology, ensuring secure and transparent energy vending.

Compact DIN-Rail Design

Easy installation in distribution boards, meter boxes, rental units, and compact environments.

Accurate Measurement

Class 1.0 accuracy with stable performance under a wide voltage range.

Multiple Vending Channels

Mobile app vending
Web portal vending
POS terminal
USSD/SMS (optional)
Utility vending system

Intelligent Load Control

Automatic disconnection when credit runs out, overload trip protection, and configurable load limits.

Strong Anti-Tamper Protection

Detects cover opening, magnetic interference, reverse connection, and bypass attempts.

Communication Options

RS485
PLC / RF (optional)
M-Bus / Modbus
Supports integration with AMI/AMR systems

Wide Application Range

Ideal for prepaid energy rollouts, rental properties, hostels, smart housing, and utility projects.

Benefits for Utilities

Zero outstanding bills - prepaid system improves revenue collection
Faster deployment with DIN-rail compact design
Reduced field losses through strong anti-tamper functions
Supports mass vending through multiple channels
Easy integration with existing STS vending platforms
